Ring Log Debarker

Ring Log Debarker

Min. Working length : 1500mm

No limit for max working length

Knife head: 5pcs

Voltage: 380v/220v/customized

Certification: CE , ISO 9001

This machine is vertical ring debarker with continuous rotary blade, could be used in conjunction with production line.

Ring type log debarker is suitable for long log, maximum working diameter is 600m, lengthways log conveyor length can be customized according to initial log length.

Model		HBP1206
Max. log diameter	mm	Ø600
Min. log diameter	mm	Ø150
Min. log length	mm	1500
Transport speed	m/min	0~30
Knife disk speed	rpm	0~160
Knife head quantity	pcs	5
Total power	kw	48.5
Overall size	mm	3100x3600x2850
Weight	kg	12000

At Hanvy, “one‑stop shop” means more than a slogan. Whether you need a single veneer dryer or a turnkey, fully automatic production line, our end‑to‑end process is built around you.

Whether you need a standalone veneer dryer or an entire, fully‑automatic plywood production line, Hanvy Machinery delivers. Our extensive product portfolio includes:

Log Cutting Lines for precise, high‑capacity debarking and cutoff.

Veneer Peeling Lines engineered for minimal waste and superior surface quality.

Veneer Drying Lines, with TÜV Rheinland accreditation, that ensure uniform, energy‑efficient moisture removal.

Gluing & Pressing Systems optimized for rapid cycle times and consistent bond strength.

Trimming, Sawing & Sanding Lines that deliver impeccable edge finishes.

Sorting & Buffering Systems, Putty & Coating Lines, and Automatic Bundle Strapping Machines—every stage, every need covered.
