Log Debarker

Log Debarker

Working length : 4ft,5ft,8ft,10ft or customized

Max.working diameter : 300~600 mm

Rotary speed: 60 m/min

Voltage: 380v/220v/customized

Certification: CE , ISO 9001

This machine adopts rotary cutting principle of non-chuck rotary veneer lathe, could remove the bark quickly and effectively, save labor cost and improve the efficiency.

* Feeding with hydraulic controlling, could improve efficiency.

* Equipped with small rotation spindle, helps to work with bend log.

* With enlarged diameter roller, increase rotary peeling speed.

* Knife-gap auto change during the debarking process.

* With high-quality steels and bearing,it’s longer service life than common debarkers.

* A front and back feed keeps the logs moving in and out of the debarker efficiently, and a

large oil pump keeps the feeds well-lubricated and working smoothly.

* A manual reverse switch with a self-reset function responds quickly for convenient and safe use.

* Working length and max working diameter could be customized.

Model		BBP3300/5	BBP2600/6	BBP2600/5	BBP1400/5
Working log diameter	mm	Ø130~500	Ø180~600	Ø130~500	Ø130~500
Max. Log length	mm	3200	2600	2600	1400
Rotary peeling speed	m/min	60	60	60	60
Centering device	Optional	Hydraulic	Hydraulic or pneumatic
Log receiving machine	Optional	Hydraulic	Hydraulic or pneumatic
Pulverizer	Optional	–	–	–	–
Total power	kw	46.5	39.5	37.7	22.7
Overall size	mm	4800×2200 x1600	4200×2400 x1700	4000×2200 x1500	2900×2200 x1500
Weight	kg	10500	8500	8000	6700

Weihai BaiShengYuan Industry is a woodworking machine manufacturer since 1956.

We won praise from overseas customers for good quality products and intimate service.

Products are exported to more than 50 countries and regions.

We’ve passed the ISO9001:2018 quality management system certification and the CE certification.

BSY product line centers on a range of standard and special plywood machines that includes plywood plant , Log debarker, veneer single-spindle rotary lathe, veneer spindle-less rotary lathe, combined rotary lathe, log charger, log conveyor, veneer guillotine, plywood performing press, Veneer Dryer, plywood Edge Trimmer, plywood Sander , etc.
